HOW DOES A ‘TYPICAL’ ACOUSTIC ENCLOSURE WORK?

Typically an acoustic enclosure works by attenuating the noise of the AC unit whilst maintaining suitable airflow and access requirements.

Figure 1 shows the simplest form of an acoustic enclosure, which includes acoustic louvres to the side and front to allow airflow in and out of the enclosure.

The method of attenuation selected depends on numerous elements including;

  • Spatial constraints – architectural requirements
  • AC Unit Airflow – typically ranging from 1m3/s – 7m3/s
  • Allowable Pressure – typically ranging from – 0 – 60 Pa
  • Required Acoustic Attenuation – usually based on planning requirement – typically between 5-20dB
  • AC Configuration – Top or Front
  • Access

Each of the above will be dealt with briefly in this design note.

Assuming all of the design considerations can be accommodated the unit(s) will still maintain the manufacturer’s efficiencies and with the correct coordination will also be covered under the manufacturer’s warranty.

AC AIRFLOW

How does this influence the design?



There is a great variance in the amount of airflow that the AC unit can circulate, typically between 1m3/s – 7m3/s. In simple terms, the greater the airflow, the more ‘open’ to air the acoustic enclosure needs to be, ultimately resulting in a bigger and more cumbersome acoustic enclosure.

The acoustic design engineer will look at the air face velocity, airway passage velocity and the passageway profile of the constriction to determine both the amount of regenerative noise and the pressures that are put on the AC unit.

PRESSURE

How does this influence the design?



The velocity of the airflow through the constrictions of the acoustic enclosure (usually acoustic louvres/attenuators) creates backpressure. The AC unit needs to have the capacity to overcome this pressure to be able to move the air efficiently. A greater level of acoustics often creates more constrictions, which in turn increases the pressure.

Generally, pressure allowances for AC units range from 0-20Pa for front-discharge units and between 20-60Pa for top-discharge.

It is often beneficial for the acoustic design engineer to request a change from front-discharge units to top-discharge units so that there is more flexibility to design an acoustic solution with higher pressures.

ACOUSTIC ATTENUATION

How much sound reduction can you expect?



Acoustics is complicated. The AC unit has a spectral content and the type of acoustic attenuation selected also has a frequency dependent performance. Therefore the amount of reduction is specific to the unit/installation.

Generally, it could be accepted that a louvred enclosure would give between 10dB and 15dB of overall attenuation, whilst an enclosure employing splitter banks could reach attenuation of up to 25dB.

For specific octave band performance values for various solutions please visit http://acoustichardware.co.uk/products.html.

TYPICAL SPATIAL PLANNING

The images below are an example of the typical dimensional requirements for noise control to be added to top discharge units. The images show access requirements, airflow space, ant-vibration mount allocation and connections and expansions.

TYPICAL ENCLOSURE EXAMPLES
